Description
SPECS
| Frame type |
Double Cradle |
| Front wheel size |
14″ |
| Rear wheel size |
12″ |
| Front brake |
Hydraulic Disc |
| Front disc |
180mm |
| Rear brake |
Hydraulic Disc |
| Rear disc |
180mm |
| Front tire |
14″ x 2.27″ |
| Rear tire |
12″ x 3″ |
| Chain |
219H |
| Gearing |
Front 10T, Rear 70T |
| Max load |
85kg |
| Fork type |
USD |
| Shock type |
Mono shock |
| Handlebar |
Alloy |
| Motor voltage |
60V |
| Peak power |
2.0kW (2.6hp) |
| Max RPM |
4,400 |
| Battery |
60V 18.2Ah Lithium |
| Controller output |
42A |
| Charger |
AC 110-240V, Output: 67.2V, 3A |
Tech
| Charge time |
5-6 hours |
| Range per charge |
35-40 Km |
| External adjustability |
Top speed, Acceleration |
| Frame construction |
High strength steel, powder coated, removable subframe, swing arm mounted motor, non linkage suspension |
| Wheelbase |
945mm |
| Ground clearance |
275mm |
| Seat height |
66cm |
| Weight |
42.5kg |
Disclaimer:
This product was designed and intended for off-road and closed-course use only. Prohibited for use on public streets, sidewalks, bike paths, or other municipal property, unless otherwise posted. Refer to local city, county, state, and federal regulations before riding. Purchasers must be 18 years or older or have parents/guardian permission. Always wear approved safety gear, and ride responsibly.
